SPECIFICATIONS
Series	WootBook Ultra
Model	Ultra Y16 (GM6HG5X-B)
Processor
Model	Ryzen 7 8845HS
Chipset Manufacturer	AMD
Base Clock	3.80 GHz
Boost Clock	5.10 GHz
Total Cores	8
Total Threads	16
Cache	16MB L3 Cache
	8MB L2 Cache
Lithography	TSMC 4nm FinFET
Memory
Supported Memory	2x SO-DIMM Slots (both unoccupied)
	Up to 96GB Maximum Capacity
	DDR5-5600MHz
Graphics
Type	Dedicated
Model	NVIDIA GeForce RTX 4050 6GB GDDR6 Graphics
Base TGP	115W ( 25W Dynamic Boost)
Additional	Integrated MUX Switch
Display
Size	16"
Panel Type	IPS (In-Plane Switching)
Native Resolution	WQXGA (2560 x 1600)
Additional	165Hz Refresh Rate
	100% sRGB
	Narrow Bezel
Storage
Supported	2x NVMe M.2 2280 PCI-E 4.0 x4 SSD Slots (both unoccupied)
Input / Output
Ports	1x USB 3.2 Gen2 Type-C (DisplayPort 1.4a Alt Mode & Power Delivery Supported)
	2x USB 3.2 Gen1 Type-A
	1x USB 2.0 Type-A
	1x HDMI 2.1
	1x Mini DisplayPort 1.4a
	1x UHS-I SD Card Reader (SD/SDHC/SDXC)
	1x RJ45 Ethernet Port
	1x Audio Combo Jack
	1x Mic-In Jack
	1x Kensington Lock Slot
	1x DC-In Jack
Audio	2x 2W Speakers
Communications
Wi-Fi	AMD Wi-Fi 6E RZ616 (AW-XB591NF) Wireless Adapter
	802.11ax
Bluetooth	Yes, v5.2
LAN	1 Gigabit (10/100/1000 Mbps) LAN Port
Integrated Input Devices
Keyboard	Single Zone RGB Backlit Membrane Keyboard
Pointing Device	Mylar Touch Pad
	Touch pad enable/disable toggle
General
Features	AMD Ryzen 8000 Series Mobile Processor
	NVIDIA GeForce RTX 40 Series Mobile Graphics
	Nahimic Audio
	100% sRGB Colour Gamut
	PCIe Gen4 Support
Webcam	HD Webcam
Operating System Support	Windows 11
Battery	4-Cell, 4s1p, 80Wh
AC Adapter	230W
Dimensions	358.44 x 266.8 x 22 mm /-1% (LxWxH)
Weight	2.4kg /- 5%
Warranty Information
Warranty	1 Year Warranty (Optional Extension to 3 Year Warranty)
